Name: D601AP articulated dumper
Brand: AUSA
SKU: D601AP

D601AP

With a 6-tonne (13,200 lb) payload, the D601AP is AUSA's versatile articulated dumper with a high payload, equipped with a front-tip skip.
Designed to cover major works, its power, torque converter transmission and 4x4 drive make it the perfect product for work involving the movement of heavy materials on every type of terrain. It is suitable for major construction work on buildings and roads and in the mining industry.
Additionally, a digital display is built into the driver's console, where you will find all of the real-time information about the machine, such as the speed, RPM, fluid levels and alarms.

Driving position

Rear folding ROPS protective structure
Closed ROPS/FOPS cab with heating
Closed ROPS/FOPS cab with heating and air conditioning

Safety

Seat belt with fasten sensor
Seat with operator's presence sensor
LED rotating beacon
Green rotating beacon
Acoustic warning for reverse gear
Emergency stop
Anti-vandal security system
Hill Holder - hill-start assist
Negative brake
Full visibility camera on the skip side
Full visibility camera on the counterweight side and proximity sensors

Lighting and driving

Road lights
Rear-view mirror
Second rear-view mirror
Third rear-view mirror

Comfort

Adjustable ergonomic seat
All-in-one joystick

Advanced equipment

Limited-slip differential on both axles
Smart Stop system
Digital display
AUSAnow fleet manager

Accessories

Front mudguards
Reverse gear acoustic warning disable switch
Car radio
Waterproof document holder
Towing ball and pintle hitch
Power socket for the trailer
Rockinger hitch with power socket

Tyres

Turf tyres 400/70-20" TL - 14PR
Pack of 4 turf wheels 560/45-22.5" TL

Parts

1,000 h maintenance kit
Standard spare wheel
Turf wheel 400/70-20" TL - 14PR
Pack of 4 turf wheels 400/70-20" TL - 14PR

Standard Optional

Unloading system	Frontal
Load capacity	13200 lb
Chassis	Articulated
Water skip capacity	2.47 cu yd
Level skip capacity	3.46 cu yd
Heaped skip capacity	4.16 cu yd
Empty weight	9900 lb
Transmission	Torque converter
Reversibility	Non-reversible

Brand	Deutz
Model	TD 3.6
Power	74.3 hp
Torque	330@1600
No. of cylinders	4
Emissions	Stage IIIB - EPA Tier 4F
Noise level (LwA)	101 dB(A)

Max. speed	15.5 mph
Maximum gradient	45 %
External turning radius	230 in
Traction	4x4
Tyres	405/70-20” (16.0/70-20)

Hydraulic circuit	Two gears pump
Flow rate	12.1 gal/min
Working pressure	2611 psi

Fuel	18.2 gal
Hydraulic system	15.8 gal

D601AP

D601AP
